1/10 Scale Escape32 VT3k 35amps Esc

VT3k 1/10 Escape32 35A ESC

The VT3k 35A Escape32 ESC is a compact, performance-focused ESC designed for 1/10-scale applications where space, clean installation, and tuning flexibility matter.

Its extremely small footprint gives builders more freedom with electronics placement while still providing the tuning capabilities of Escape32 firmware.

Every ESC is individually built, configured, and tested by VT3k Electronics and ships with a VT3k Tune already installed.

Features

• 35A ESC / 40A continuous capability
• Extremely compact footprint for 1/10-scale applications
• Escape32 firmware
• Wi-Fi programming from your phone or laptop
• Selectable external BEC voltage
• 3A external BEC
• VT3k Tune installed
• Individually tested before shipping
• Red JST connection included for direct-power servos

Power & BEC Setup

The VT3k Escape32 uses a 3A external BEC, which helps us maintain the ESC's extremely compact size.

The 3A BEC is intended to power your receiver, lights, and other low-current accessories. It is not recommended for powering the steering servo.

For the best servo performance, VT3k recommends using a direct-power servo powered directly from the battery. This allows a capable servo to receive the voltage and current it needs without being limited by the ESC's 3A BEC.

You may also use a separate high-current external BEC properly matched to your servo.

All VT3k 1/10 Escape32 ESCs come equipped with a red JST connection for direct-power servo setups.

Because the BEC is external, you can select your desired BEC voltage from the available options when ordering, and VT3k will configure it accordingly during the build.

Wi-Fi Programming

Programming is simple. Connect your compatible Wi-Fi module to the ESC's JST programming connection, then search for the Escape32 Wi-Fi network from your phone or laptop.

Once connected, the Escape32 settings page will open, giving you access to the available tuning parameters without requiring a traditional programming box.

Getting the Best Performance

To get the most from your ESC, we recommend using:

• Proper motor gearing for your vehicle and application
• A direct-power servo or appropriately rated external servo BEC
• Quality batteries, connectors, and wiring
• Proper cooling and airflow
• Regular temperature checks when testing new gearing or motor combinations

Always monitor ESC and motor temperatures, especially after changing gearing, motor, battery voltage, or vehicle setup.

Custom Startup Tunes

Escape32 also supports custom startup tunes. Customers who want to customize their ESC can use compatible tune code through the Escape32 settings.

Looney Tunes

Looney:d=4,o=5,b=140:32p,c6,8f6,8e6,8d6,8c6,a.,8c6,8f6,8e6,8d6,8d#6,e.6,8e6,8e6,8c6,8d6,8c6,8e6,8c6,8d6,8a,8c6,8g,8a#,8a,8f

Super Mario Bros Intro

:b=115,o=5,d=4:16e6,32p,16e6,16p,16e6,16p,16c6,16e6,16p,16g6,8p,16p,16g5,2p

VT3k Escape32 Limited Warranty

The VT3k Escape32 ESC is backed by a 4-week limited warranty from the original date of purchase against defects in materials and workmanship.

If a manufacturing defect is confirmed during the warranty period, VT3k Electronics may, at its discretion, repair or replace the affected ESC.

The warranty does not cover damage resulting from incorrect installation or wiring, reverse polarity, water or moisture, crashes or physical damage, excessive heat, improper gearing or overloading, improper programming, incompatible electronics, misuse, or unauthorized modification or repair.

Removing the ESC from its original heat shrink voids the warranty.

Warranty service may require proof of purchase, order number, a description of the issue, and photos or video of the ESC and installation. VT3k Electronics may request that the ESC be returned for inspection.

The warranty applies to the original purchaser and is non-transferable. Warranty coverage is limited to the ESC itself and does not cover other components connected to the ESC.

Compact size. Full Escape32 tuning. Built, tuned, and tested by VT3k.
